The lifting motor is positioned high, enabling the truck to operate in environments where ground water is present.
The U-shaped steering wheel design, combined with the front-positioned multi-way valve operating device, ensures effortless and comfortable operation.
Fast charging allows the battery to be fully charged in 2-3 hours. The intelligent high-frequency charger, utilizing automotive charging technology, achieves a working efficiency of over 95%.
The new SHE display offers three distinct drive modes, delivering superior acceleration performance. It provides higher lifting performance compared to diesel forklifts in the industry.
CAN-bus technology simplifies diagnostics and troubleshooting processes.
Manufacturer's type designation | CPD25 | CPD30 | CPD35 | |||
Drive | / | Electric | Electric | Electric | ||
Type of operation | / | Seated | Seated | Seated | ||
Load capacity/rated load | Q(kg) | 2500 | 3000 | 3500 | ||
Load centre distance | c(mm) | 500 | 500 | 500 | ||
Load distance,centre of drive axle to fork | x(mm) | 478 | 478 | 483 | ||
Wheelbase | y(mm) | 1620 | 1800 | 1800 | ||
Weights | ||||||
Service weight incl.battery | kg | 3600 | 4070 | 4480 | ||
Axle loading, laden front/rear | kg | 5500/600 | 6390/680 | 7140/840 | ||
Axle loading, unladen front/rear | kg | 1540/2060 | 1750/2320 | 1960/2520 | ||
Wheels、Chassis | ||||||
Type:solid,pneumatic | / | Pneumatic | Pneumatic | Pneumatic | ||
Tyres size,front | / | 7.00-12-12PR | 28x9-15-14PR | 28x9-15-14PR | ||
Tyres size,rear | / | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | ||
Wheels,number front/rear(x=driven wheels) | / | 2x/2 | 2x/2 | 2x/2 | ||
Track width,front | b10(mm) | 973 | 1004 | 1004 | ||
Track width,rear | b11(mm) | 982 | 982 | 982 | ||
Basic Dimensions | ||||||
Mast/fork carriage tilt forward/backward | α/β(°) | 6/10 | 6/10 | 6/10 | ||
Lowered mast height | h1(mm) | 2070 | 2070 | 2185 | ||
Free lift | h2(mm) | 135 | 140 | 145 | ||
Lift height | h3(mm) | 3000 | 3000 | 3000 | ||
Extended mast height | h4(mm) | 3974 | 4079 | 4079 | ||
Height of overhead guard | h6(mm) | 2150 | 2150 | 2150 | ||
Seat height | h7(mm) | 1130 | 1130 | 1130 | ||
Coupling height | h10(mm) | 580 | 580 | 580 | ||
Overall length | l1(mm) | 3568 | 3773 | 3818 | ||
Length to face of forks | l2(mm) | 2498 | 2703 | 2748 | ||
Overall width | b1(mm) | 1150 | 1226 | 1226 | ||
Fork dimensions | s/e/l(mm) | 40/120/1070 | 45/125/1070 | 50/125/1070 | ||
Fork carriage width | b3(mm) | 1040 | 1100 | 1100 | ||
Ground clearance,laden,under mast | m1(mm) | 135 | 135 | 135 | ||
Ground clearance,centre of wheelbase | m2(mm) | 150 | 150 | 150 | ||
Aisle width for pallets 1000x1200 crossways | Ast(mm) | 3908 | 4078 | 4123 | ||
Aisle width for pallets 800x1200 lengthways | Ast(mm) | 4108 | 4278 | 4323 | ||
Turning radius | Wa(mm) | 2230 | 2400 | 2440 | ||
Performance Data | ||||||
Travel speed,laden/unladen | km/h | 13/14 | 13/14 | 12/13 | ||
Lift speed,laden/unladen | m/s | 0.26/0.34 | 0.32/0.40 | 0.30/0.40 | ||
lowering speed,laden/unladen | m/s | <0.6 | <0.6 | <0.6 | ||
Max.drawbar pull,laden/unladen | N | 13000/14000 | 14000/15000 | 14000/15000 | ||
Max.Gradient performance,laden/unladen S2 5 min | % | 15/15 | 15/15 | 15/15 | ||
Service brake | / | Hydraulic | Hydraulic | Hydraulic | ||
E-Motor | ||||||
Drive motor rating S2 60 min | kw | 11 | 11 | 11 | ||
Lift motor rating at S3 15% | kw | 16 | 16 | 16 | ||
Battery standard | / | Lion | Lion | Lion | ||
Battery voltage/nominal capacity K5 | V/Ah | 76.8/277 | 76.8/277 | 76.8/277 | ||
option:76.8/412/554 | option:76.8/412/554 | option:76.8/412/554 | ||||
Battery dimensions l/w/h | mm | 770/600/680 | 770/650/680 | 770/650/680 | ||
Other Details | ||||||
Type of drive control | / | AC | AC | AC | ||
Operating pressure for attachments | MPa | 17.5 | 17.5 | 17.5 | ||
Oil volume for attachments | l/min | 36 | 36 | 36 | ||
Sound level at driver's ear according to EN 12053 | dB/(A) | 74 | 74 | 75 |
