The standard high-capacity lithium-ion battery, with a capacity of 554Ah and efficient fast-charging technology, requires only 2-3 hours for a full charge, ensuring operation across multiple shift.
Turning deceleration function ensures safer driving.
The trucks are equipped with Curtis or Inmotion controllers, along with the CAN-bus technology, making diagnostics and troubleshooting easier.
The trucks feature large-diameter tires, providing better performance for outdoor applications and a more comfortable driving experience. Solid tires come as the standard configuration.
The open design of the controller and lifting motor allows for more convenient maintenance.
Optional Grammer suspension seats and fingertip control technology are available for a more comfortable driving experience.
Manufacturer's type designation | CPD50 | |||
Drive | / | Electric | ||
Type of operation | / | Seated | ||
Load capacity/rated load | Q(kg) | 5000 | ||
Load centre distance | c(mm) | 500 | ||
Load distance,centre of drive axle to fork | x(mm) | 563 | ||
Wheelbase | y(mm) | 1950 | ||
Weights | ||||
Service weight incl.battery | kg | 6950 | ||
Axle loading, laden front/rear | kg | 10610//1360 | ||
Axle loading, unladen front/rear | kg | 2750/4200 | ||
Wheels、Chassis | ||||
Type:solid,pneumatic | / | Solid | ||
Tyres size,front | / | 250-15 | ||
Tyres size,rear | / | 23x9-10 | ||
Wheels,number front/rear(x=driven wheels) | / | 2x/2 | ||
Track width,front | b10(mm) | 1200 | ||
Track width,rear | b11(mm) | 1125 | ||
Basic Dimensions | ||||
Mast/fork carriage tilt forward/backward | α/β(°) | 6/10 | ||
Lowered mast height | h1(mm) | 2250 | ||
Free lift | h2(mm) | 150 | ||
Lift height | h3(mm) | 3000 | ||
Extended mast height | h4(mm) | 4117 | ||
Height of overhead guard | h6(mm) | 2265 | ||
Seat height | h7(mm) | 1130 | ||
Coupling height | h10(mm) | 490 | ||
Overall length | l1(mm) | 4110 | ||
Length to face of forks | l2(mm) | 3040 | ||
Overall width | b1(mm) | 1500 | ||
Fork dimensions | s/e/l(mm) | 50/150/1070 | ||
Fork carriage width | b3(mm) | 1380 | ||
Ground clearance,laden,under mast | m1(mm) | 135 | ||
Ground clearance,centre of wheelbase | m2(mm) | 165 | ||
Aisle width for pallets 1000x1200 crossways | Ast(mm) | 4453 | ||
Aisle width for pallets 800x1200 lengthways | Ast(mm) | 4653 | ||
Turning radius | Wa(mm) | 2690 | ||
Performance Data | ||||
Travel speed,laden/unladen | km/h | 14/15 | ||
Lift speed,laden/unladen | m/s | 0.30/0.42 | ||
lowering speed,laden/unladen | m/s | 0.38/0.30 | ||
Max.drawbar pull,laden/unladen | N | 18500/18000 | ||
Max.Gradient performance,laden/unladen S2 5 min | % | 15/20 | ||
Service brake | / | Hydraulic | ||
E-Motor | ||||
Drive motor rating S2 60 min | kw | 20 | ||
Lift motor rating at S3 15% | kw | 26 | ||
Battery standard | / | Lion | ||
Battery voltage/nominal capacity K5 | V/Ah | 76.8/554 | ||
option:76.8/412 | ||||
Battery dimensions l/w/h | mm | 1200/810/610 | ||
Other Details | ||||
Type of drive control | / | AC | ||
Operating pressure for attachments | MPa | 18.5 | ||
Oil volume for attachments | l/min | 65 | ||
Sound level at driver's ear according to EN 12053 | dB/(A) | 75 |
